Canon

Canon Plotwave 5000

(No reviews yet) Write a Review
Weight:
550.00 LBS
Please Call 516-433-7440 for a quote or email Sales@arescoinc.com

Description


PlotWave 5000/5500

Large Format Technical Document Management with Advanced Security Options
  • PlotWave 5000 / 5500 is a highly configurable 2 or 4 roll printer and copier with optional integrated 600 dpi color/mono scanner.
  • Large format printing system available in a space saving single-footprint design.
  • The top delivery tray incorporates air separation technology and neatly collates and stacks up to 100 E-size plots.
  • Standardized security features, including AES 256 data encryption, secure boot, and Access Management user authentication enabled.



PlotWave 5000/5500 Series

STANDARD SYSTEM CONFIGURATION

2-ROLL PRINTING SYSTEM (STANDARD)

Productive large format monochrome printer with ClearConnect multitouch user panel.

STACKING SYSTEM

Integrated Top Delivery Tray. Up to 100 sheets E-size/A0.

ROTATABLE CLEARCONNECT MULTITOUCH USER INTERFACE

Consistent look and feel from every angle of your workflow, standard, including Smart Inbox, SmartAccess, and Live Preview.

TILT AND SWIVEL ClearConnect MULTITOUCH USER INTERFACE

Fully automated roll media switch to guide the media to the Top Delivery Tray or back output depending on the user application.

ClearConnect WORKFLOW SOFTWARE

Drivers: Driver Select for Microsoft Windows, Driver Express PostScript 3 driver. Publishers: Publisher Mobile for IOS and Android, Publisher Express, Publisher Select 3 for Microsoft Windows.

STARTER KIT INCLUDED

1 bottle toner 450 g, 1 bottle developer 1,750 g, 1 roll 36" 20 lb. bond paper (75 g/m2).

EARTHQUAKE PROVISION1

Help secure the printer against moving or tilting during an earthquake. This provision enables the user to secure the printer to a sturdy connection of the building.

OPTIONAL SYSTEM CONFIGURATIONS

OFFICE SPACE SAVING SCANNING SYSTEM

Scanner Express with Image Logic technology, integrated scanner positioned on top of the printer to save office space.

CUTSHEET TRAY

Capacity: 250 pages; Sizes: A/A4 size–C/A2 size

STACKING SYSTEMS

Stacker Select, 400-sheet capacity

ROLL MEDIA CAPACITY UPGRADE

Double roll media capacity from 2- to 4-roll system

REMOVABLE HARD DISK

For secure environments, hard disk can easily be removed from the printer system to help secure data integrity.

TECHNOLOGY

IMAGING TECHNOLOGY

Electrophotography (LED) with Organic photoconductor (OPC).
Radiant Fusing Technology with instant warm-up. Clean toner refill system. Virtually no ozone emission.

FUSING TECHNOLOGY

Instant warm-up, contactless fusing, low power consumption (heating on-demand).

TONER/TYPE

Black toner: 900 grams per toner kit (450 grams/ bottle).

PRODUCTIVITY

SPEED (PRINT AND COPY)



PlotWave 5000:
8-D/A1-sizes2 per minute 4-E/A0 sizes3 per minute
PlotWave 5500:
10-D/A1-sizes2 per minute 5-E/A0 sizes3 per minute



FIRST PRINT OUT TIME4

<40 seconds

FIRST COPY OUT TIME5

<40 seconds

1 Excluding cable/chain and mounting material.
2 D-size (34"" x 22"") / A1 size (841 x 594 mm).
3 E-size (36"" x 48"") / A0 Size (841 x 1189 mm).
4 One A1 landscape print made from the smart inbox, on 64 g media, back output, lines, and text mode.
5 One copy made with A1 original in landscape on 64 g media, back output, background compensation off, custom width 841 mm, custom length 594 mm.

QUALITY

PRINT RESOLUTION

600 x 1200 dpi

MINIMUM LINE WIDTH (ISO/IEC 13660:2001E)

0.00236" (0.06 mm)

1:1 LINE ACCURACY

< 0.3%

SIZE AND WEIGHT

SIZE MAIN ENGINE (W x D x H)

61.6" x 31.7" x 58.9" (1,563 mm x 803 mm x 1,495 mm) (Height of 58.0" includes Top Delivery Tray)

SHIPPING DIMENSIONS (W x D x H)

58” x 34” x 50” (1,470 x 850 x 1,280 mm)

WEIGHT MAIN ENGINE

516 lb. (234 kg)

SHIPPING WIEGHT MAIN ENGINE

629 lb. (285 kg)

MEDIA HANDLING

MEDIA CAPACITY

2 or 4 rolls; manual feed of cutsheet media. Cutsheet tray.

PAPER CUTTING

Cutter included in the drawer for fast and easy roll media switching.

MAXIMUM MEDIA CAPACITY

2 rolls (650' L x 36" W): 3,900 sq. ft. If 4 rolls: 7,800 sq. ft.

MEDIA SIZES ROLL

ARCH: B, C, D, E, E1, 30"", 21"", 15"" ANSI: B, C, D, E
ISO: A3, A2, A1, A0, B1, B2, B1_700, B2_700

MEDIA SIZES CUTSHEET TRAY

Short-edge feed (portrait):
A3, B4, A, B, A+, B+, Carto B4, 230 x 310 mm, 310 x 440 mm
Long-edge feed (landscape):
A3, A2, B4, B3, B, C, B+, C+, Carto B4, Carto B3, 15"" x 21"", 310 x 440 mm, 440 x 594 mm

MEDIA WEIGHT

Bond: 16–28 lb.(60–110g/m2). Film: 3.5 mil.

ROLL LENGTH

Up to 650' (200 m)

ROLL WIDTH

11"–36" (11",12",15",17",18",21",22",24",30",34",36") (279–914mm)

MINIMUM PRINTED LENGTH

11" (279 mm)

MAXIMUM PRINTED LENGTH

577' (176 m)

ROLL MEDIA TYPE

Paper: Engineering Bond, Vellum, Recycled Bond, Tinted Bond Xtreme #27 Bond Film: Polyester 3.5 mil

CUTSHEET MEDIA TYPE

Paper: Engineering Bond, Recycled Bond, Tinted Bond Xtreme #27 Bond

AUTOMATIC ROLL MEDIA HANDLING

Automatic width detection
Automatic roll media selection for optimized productivity and media saving, based on drawing size, media type, roll width, and finishing.
Automatic roll switching when end of roll is reached.

USER INTERFACE

DESCRIPTION

ClearConnect multitouch user panel

SIZE (W x D x H)

11.8" x 8.7" x 1.6" (300 x 220 x 40 mm), 10.4" (diag.) color LCD

RESOLUTION

800 x 600 pixels (SVGA)

TECHNOLOGY

Projective capacitive touch

OPERATION

3 hard buttons: [Wake-up], [Stop, interrupt, abort], [Home]
Multitouch functions: tap, double tap, pinch, 2-finger pinch, swipe, flick, and spread.

INTERFACE DESIGN

Distinctive user interface with intuitive navigation and clearly defined levels of operation.

FEATURES

View optimization: Tilt ClearConnect (-4 to +45 degrees) and swivel (-45 to +180 degrees). Status light (red, orange, green).
USB 2.0 interface with indication light.
Switch instantly between 2 languages, select from 21 languages.

CONTROLLER

DESCRIPTION

High performance POWERsync controller with Windows 10 IoT Enterprise LTSC, 64-bit

PROCESSOR

Dual Core, Dual Thread Celeron® G4900 at 3.10GHz

MEMORY

4 GB DDR4

VIDEO

Intel HD Graphics, 1GHz

HARD DISK

500 GB, 7200 rpm (standard)

TPM

TPM2.0

CLIENT OPERATING SYSTEM SUPPORT

Windows 7 / Windows 7 64 bits / Windows 8.1 / Windows 8.1 64 bits / Windows 10 / Windows 10 64 bits / Windows Server 2008 R2 64 bits / Windows Server 2012 64 bits / Windows Server 2012 R2 64 bits/Mac OS 10.10 / Mac OS 10.11 / Mac OS 10.12 (PostScript 3 driver support only for Mac OS)

INTERFACE

2 x Ethernet 100 Mbits/s, 1Gbit/s TCP/IP: DHCP, IPv4, IPv6, HTTPS Discovery: APIPA, WS-Discovery, SNMPv3

PAGE DESCRIPTION LANGUAGE

TIFF, JPEG, HPGL, HPGL2, DWF, C4, Calcomp 906/907/951, CALS, NIRS, NIFF, PS/PDF (optional)

PRINTING PROTOCOL

LPR, FTP, WebDav, WSD print FTP
Pull from SMB, FTP
Pull from cloud (retrieve from WebDAV-based clouds) HTTP/HTTPS (used by Publisher Express)
Print from home folder via optional access management

BACKCHANNEL PROTOCOL

SNMPv3, Wave interface, WS-Discovery

SECURITY

NEW SET OF SECURITY FEATURES

E-shredding, IPSec, IP filtering/Access Control Lists, HTTPS, SNMPv3, audit logging, AES256 Disk Encryption, 802.1x Authentication, network protocol enable/disable, LDAP integration, Active Directory Integration,
User authentication on local ClearConnect user panel and via Express WebTools (LDAP/Active Directory credentials, smart card) for scan/copy/print. Configure HTTPS Certificates. Allow disabling TLS1.0 and 1.1 protocols (no response to network scan) and enable TLS 1.2 with stronger cipher. Embedded FIPS 140-2 Certified Trusted Platform Module (TPM) and BitLocker 256 AES hard disk encryption, hard disk wipe,
Configurable CA certificate, Disable Network Ports and Protocols, Security Event Logging, Single Sign-on. Options: Removable hard disk, McAfee antivirus, McAfee Application control (whitelisting).

ACCESS MANAGEMENT

Help provide secure access to device by users keying in password on the ClearConnect multitouch operator panel or get access with a Smart Card by connecting a card reader (including contactless). Authorization is managed by using Active Directory.

CLOUD SUPPORT

Unlimited user and/or Administrator authenticated cloud support via WebDAV and/or third-party provider:
e.g. Microsoft SharePoint, Dropbox, Box.com, box.net, Google Drive, Microsoft OneDrive, Amazon Cloud Drive, Cloudsafe, MyDisk. The cloud user authentication can either be preconfigured by the administrator or done by the user at the time of accessing the specific cloud.

TRANSFORMATIONS

Scaling (scale-to-fit page, reduce when image too large to avoid clipping or to custom factor, scale page size to standard size), Rotation, Shift (automatic or user defined), Adding/removing trailing/leading edge, Mirror, Black intensity in poster mode, Print optimization (standard, lines/text, poster). Color Highlight and Dark Original. Area to erase (area of interest).

SCANNER EXPRESS (OPTIONAL)

DESCRIPTION

Integrated Contact Image Sensor (CIS) Color scanner with Image Logic technology

SCAN RESOLUTION

600 x 600 dpi (Selectable 100, 200, 300, 400, 600 dpi)

SCAN SPEED

Up to 49.8 ft./min. (15.2 m/min.) Black & white scanning Up to 33.1 ft./min. (10.1 m/min.) Copying
Up to 16.4 ft./min. (5.0 m/min.) Color scanning

SCAN FORMATS

TIFF, PDF, PDF/A, JPEG, CALS, multipage PDF, multipage PDF/A and multipage TIFF

SCAN TEMPLATES

Extensive number of scan templates to standardize common scan settings and destinations

SCAN PROTOCOL

FTP, SMB, scan to cloud (push to WebDAV-based clouds)

SCAN DESTINATION

Local USB flash drive, FTP, SMB, Smart Inbox on Controller, Optional Local Home folder (LDAP), mobile device via Mobile WebTools, WebDAV clouds.

SCAN NAMING

Preset naming with auto numbering for productive scanning or file name on the ClearConnect user panel

ORIGINAL WIDTH

8.2"–36" (208–914 mm), automatic width detection

ORIGINAL LENGTH

8.2"–52.5" (208 mm–16 m), auto length detection

ORIGINAL THICKNESS

Maximum 0.03" (0.8 mm) non-rigid documents

ZOOM (COPY)

1:1, Scale to media size, Scale to standard format. Custom: 10–1,000%

ORIGINAL TYPE PRESETS

Lines & Text standard, Folded Lines & Text, Lines & Text draft, Dark Original, Colored Original, Photo, Blueprint, Map, Artwork

SCANNER SIZE (W x D x H)

43" x 12" x 5.5" (1,097 x 308 x 140 mm)

SCANNER WEIGHT

55 lb. (25 kg)

ENVIRONMENTAL

ACCOUSTIC SOUND POWER

Standby and sleep: less than 26 dB. Print mode: less than 52 dB

OZONE CONCENTRATION

< 0.005 mg/m3, < 0.002365 PPM (0.25% of permitted limit value)

HEAT EMISSION

Ready: 66 W; Active: 1.5 kW

POWER REQUIREMENTS

100–240 V; 50/60Hz

POWER CONSUMPTION

Sleep mode: <2 W Ready mode: 66 W Active mode: 1.7 kW

SAFETY/EMC MARKS AND ENVIRONMENTAL LABELS

CE, TUV GS, CETECOM, ENERGY STAR 3.0, FEMP, Rohs, CCC, VCCI TüV GS, c-UL-US, CB, RCM, EPEAT, EAC, FCC Class A, VCCI Class A

RECYCLABLES

Printer: made of steel or highly recyclable plastics: up to 95% of the engine can either be upcycled or recycled. Remaining 5% are nontoxic waste.
Prints: very good deinkability when recycled.
Toner: bottles made of highly recyclable HDPE (High Density Polyethylene)

CLEARCONNECT WORKFLOW SOFTWARE

JOB SUBMISSION

The ClearConnect software suite consists of a variety of applications with the same user interface. Create, retrieve, and/or send jobs from drivers (Driver select for Microsoft Windows, Driver Express for Adobe PostScript 3 for Microsoft Windows or Apple OS), external locations (SMB, FTP, LPR, WebDAV), Mobile devices via Express WebTools and Publisher Mobile, USB fash drive, Cloud services, and optional Home folder (LDAP).
1-click printing from USB, 1-click printing from previous sent jobs via Print SmartAccess on ClearConnect user panel. The Smart Inbox on the ClearConnect user panel enables the job preview: swipe between your jobs for print selection and preview. Pan to view the image in detail (zoom).
With the template-oriented Publisher Select 3 submitting multiple fles in batches is supported. Print multiple times and sort by page or set. Media saving automatically rotates print fles to optimize media usage.

SMART INBOX

Personalized Smart Inbox: History, Manage Queue, Manage History, Express WebTools, Secured Controller Access

QUEUE MANAGEMENT

Spool memory provides a queuing system for print and copy jobs. This enables multiple users to send print and copy jobs at the same time. Customize priority settings for copy and print jobs in the queue.
The Job Queue overview gives access to job names, owners, and status including required media. Jobs can be paused, deleted, and placed on top of the queue.

PRINT MANAGEMENT AND ACCOUNTING

View the counter history at preferred time periods, per job or total overview in Express WebTools. View, create, edit, and delete stamp templates.
Optional uniFLOW support, log in with your personal uniFLOW Queue on the ClearConnect User interface. Supports manual authentication, card readers, and contactless card readers.

DEVICE MANAGEMENT

Express WebTools provide administrators the tools to manage the device remotely via the web: e.g. check printer status; define default settings for print, copy, and scan; define access; security; accounting; remote shutdown; software update and restart; power on/off timer; system behavior; queue management; license management; view, create, edit, and delete stamp templates; etc.

SCAN TO COLOR INKJET

Scan directly to iPF 600/700/800/TX- 2000/3000/4000/5200/5300/5400 series via Publisher Select 3 (hotfolder)

STACKER SELECT

DESCRIPTION

Integrated productive stacker with high capacity and tray full sensor

CAPACITY

400 pages
